Specification:
Type                                                                : Guided / Unguided
Float material                                                  : SS304/SS316/PP
Board scale                                                     : 6” Wide, 1 meter long in “C” Section
Material of board                                             : Aluminium with Powder Coated
Pointer cradle                                                  : Carbon Steel Pointer with 6 Nylon Rollers for Frictionless gliding.
Pulley housing                                                 : Dust proof Aluminium
Connecting pipe                                              : Carbon Steel Powder Coated
Rope                                                               : SS304/SS316/PP
Range                                                             : 1500 to 20000 mm
Least count                                                     : 5 mm
Tensioner                                                        : Cadmium plated steel spring housed in CS/PP enclosure.
Anchor                                                            : Weldable - SS304/SS316
                                                                          Weighted - SS304/SS316/PP
Max Operating pressure of float                     : Atm.
Maximum operating temperature                   : 80°C (PP) / 150°C (SS)
Minimum Specific gravity of fluid                   : 0.75

Product   /   Level   /  LGB .

       Features:

• Dust-proof pulley housing

• Guided & unguided construction available

• Polypropylene construction for chemical applications

• Sleek float with large diameter for higher accuracy


  LGB
  Level gauge-Float & Board

FGB is economical, easy to install for liquid level indication in bulk storage tanks under low pressure condition.it is assembled at site by the user FGB are widely used for oil tanks, large acid tanks where in there is not much or pressure i.e. non pressurized tanks based on simple Rope & Float Principle.

       Application:

• Over ground / overhead storage tanks

• Water / DM water storage tanks

• Storage tanks for oil & petroleum products

• All non-hazardous & non-pressurized tanks
